A Directory Full of Question Marks: Seeding PingOne

The first full PingOne seed I ran from Windows PowerShell 5.1 produced a directory where José was Jos<?>, the Han names were rows of question marks, and one surname had lost a character entirely. The same seed from PowerShell 7, against the same environment, stored every name perfectly.

The cause is not PingOne’s. Windows PowerShell sends a string request body as ISO-8859-1 when no charset is named, whatever the machine’s code page. An accented e goes out as the lone byte E9 and comes back stored as U+FFFD. A Han character goes out as ?, and that is what the directory keeps.

What lifts it above a footnote is that PingOne was the sixth provider, written from scratch after the other five, and it found something all six had been quietly exposed to. The fix is now one function in Core that every provider sends through:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10

# The body goes out as UTF-8 bytes with the charset named, on both editions. A string
# body is sent by 5.1 as ISO-8859-1 when no charset is named, whatever the machine's code
# page: observed against PingOne, an accented e went out as the lone byte E9 and was
# stored as U+FFFD, and a Han character as '?'.
elseif ($Body -is [string]) {
    $bytes = [System.Text.Encoding]::UTF8.GetBytes($Body)
}
else {
    $bytes = [System.Text.Encoding]::UTF8.GetBytes(($Body | ConvertTo-Json -Depth $JsonDepth -Compress))
}

Responses are decoded from their raw bytes for the mirror-image reason. Windows PowerShell decodes by the declared charset and falls back to Latin-1, and at least one provider’s API declares none.

This is part seven, and the last provider post, after what makes seed data useful, Active Directory, Entra, Okta, Authentik and FreeIPA.

What lands in the environment

Four minutes to seed the full 319 users, a minute to tear down, ten seconds to report. -Tier Core seeds every object type with the nineteen designed users alone, in about twenty-five seconds, so the loop while you are working on behaviour costs less than the time it takes to read the output.

The populations carry more weight here than in the other providers, because they are the containment mechanism and PingOne gives a user exactly one. Four of them: the one holding most of the directory and the one the dynamic filter keys on, a second so that anything assuming a single population is wrong, a third that the population-scoped group is bound to, and one deliberately empty, since an empty container is a state plenty of code has never seen.

Everything it creates carries the prefix on its name and the tag somewhere provable, and nothing else in the environment is created, changed or removed. The list of what it will not touch runs long and is on the provider’s page: sign-on policies, MFA and risk policies, administrator roles, certificates, branding, gateways, the environment’s default population, PingOne’s own applications, and any object it did not create, including a trial’s sample data.

Two environments, and a message that sends you the wrong way

The first thing that cost me an evening has nothing to do with seeding.

A PingOne worker application gets its token from the environment it lives in, not the one it manages. A trial hands you an Administrators environment and a sandbox, and the console’s application list opens on Administrators, so that is where most workers end up. Asking the sandbox’s token endpoint for a token with that worker is refused with invalid_client.

That message is also what a disabled application produces, and what a mistyped secret produces. Three quite different problems, one answer, and the answer names none of them.

1
2
3

Connect-TestEnvironment -Provider PingOne -EnvironmentId <sandbox guid> `
    -ClientId <worker guid> -ClientSecret $secret `
    -AuthEnvironmentId <administrators guid> -SaveSecret

-AuthEnvironmentId says where the application lives. It defaults to -EnvironmentId, correct when the two are the same and harmless to state when they are not.

The region has the same shape of problem. PingOne serves North America, Europe, Canada, Asia-Pacific and Australia from different hostnames, and an environment id does not tell you which. Ask the wrong regional host and you get a 404 that reads as a missing environment. -Region is named and never guessed, and the error says which host was tried. The console’s own hostname is the reliable way to tell.

The connection is then validated before it is stored, by reading the environment once. A credential accepted at connect time and refused on the first real call hands somebody an error about users when the problem is the credential.

-SaveSecret writes the worker secret to ~/.testenvironment/<environment>.pingone.secret once the connection has proved itself, and -UseStoredSecret reads it back later.

A user with nowhere to put a tag

Every other provider in the module has somewhere to write a marker on a user. Active Directory has adminDescription, Entra has a directory extension, Okta has a profile attribute, Authentik has free-form attributes, FreeIPA has userclass.

A PingOne user has account, address, email, enabled, identityProvider, lifecycle, mfaEnabled, name, population, username and verifyStatus. Not one of them is free text this module could claim without stepping on something real.

So the provider makes its own field. It creates a custom attribute, zzTestSeedTag, and writes the tag into it on every user it creates. Nothing else writes that attribute, because the module is what created it.

Ownership then has two routes, and the primary one is containment:

1
2
3
4
5
6

Users          in a seeded population, or carrying the tag attribute
Populations    tag in the description AND prefix on the name
Groups         tag in the description AND prefix on the name
Applications   tag in the description AND prefix on the name
Resources      tag in the description AND prefix on the name
Attributes     schemaType CUSTOM AND named in this provider's data file

Every seeded user is in exactly one seeded population, so teardown enumerates those populations and removes what is in them. The tag attribute is the fallback, for a user somebody moved out of a seeded population by hand, and on its own it is enough.

The other types need both pieces. The tag alone could be pasted into a real object’s description by accident, and the prefix alone is exactly the name-matching this module refuses to do anywhere.

PingOne’s own applications and built-in resources are refused by type whatever their description says, so renaming one in the console cannot bring it within teardown’s reach. Custom attributes are claimed only when they are CUSTOM and declared in the provider’s data file, since a CORE or STANDARD attribute is the platform’s however it is named.

Ask the schema before you filter on it

Finding the tagged users means filtering on the custom attribute, and filtering on an attribute the schema does not have is refused with HTTP 400 REQUEST_FAILED. That code is broad enough that ignoring it would hide real failures too.

The attribute is absent in exactly two situations, and both are ordinary: a fresh environment before the first seed, and an environment after teardown, since teardown removes the attribute last. So a report run before seeding anything, and a teardown run twice, both used to hit it.

1
2
3
4
5
6
7

$attributeName = $script:PingOneSeedAttributeName
$attributeExists = $false
foreach ($schema in (Invoke-PingOneRequest -Method GET -Path 'schemas' -Paginate -Connection $Connection)) {
    $match = @(Invoke-PingOneRequest -Method GET -Path "schemas/$($schema.id)/attributes" -Paginate -Connection $Connection |
            Where-Object { $_.name -eq $attributeName })
    if ($match) { $attributeExists = $true; break }
}

Asking the schema is deterministic and needs no guess about which error code means “no such attribute”. Two extra calls buy a discovery path that works on an empty environment.

The filter that follows carries a guard that reads like paranoia and is not:

1
2
3
4

# Nulls filtered out explicitly, so no path can ever hand teardown a user with no
# id - which would become "DELETE users/" with nothing after the slash.
$tagged = @(Invoke-PingOneRequest -Method GET -Path 'users' -Paginate -Connection $Connection `
        -Query @{ filter = $filter } | Where-Object { $null -ne $_ -and $_.id })

An ignored error in this provider’s request helper returns $null, and @($null) in PowerShell is a one-element array holding nothing. Unguarded, a foreach over it runs once, with a user object that has no id, and builds a delete path ending in a slash. Whatever that would have hit, it is not something I wanted to find out against a live environment.

The nineteen

The designed users carry their real given and family names; only their usernames and emails take the prefix, and the emails sit under a reserved domain that cannot receive mail. What each row is for:

A disabled user who still holds every group membership, because disabling an account removes it from nothing and membership reports routinely count it as active. A user with the MFA-enabled flag off where most of the directory has it on, with no MFA device or policy created behind it, since the flag is a field and the enrolment is not. A badge value that PingOne really enforces as unique, so a second user with the same one is refused outright.

And the nine written in Han with an ideographic space, a surname above the basic multilingual plane, Cyrillic, Greek, Arabic, Devanagari, a decomposed name, a Turkish dotless i and an eszett. Same nine as every other provider, from the same shared file, every username plain ASCII. They are the only coverage this module has for how string handling goes wrong, and the first PingOne seed proved they earn the space.

STRING or JSON, so the boolean is text

PingOne refuses a custom attribute of any type but STRING or JSON. Ask for BOOLEAN and you get INVALID_DATA on type: must be STRING or JSON.

The contractor flag is therefore the text "true" or "false", and that puts a nasty row in the seed data for free. In PowerShell the string "false" is not falsy. Any code that does this:

1

if ($user.contractor) { ... }

reads every user in the directory as a contractor, including the twelve whose flag says otherwise. The attribute exists in the seed because that mistake is easy, common, and produces a confidently wrong report and no error at all.

One of the five attributes is declared unique, and PingOne enforces it properly: creating a second user with the same badge value is refused with INVALID_DATA. Another is multivalued, and one is JSON, so an export that flattens structured values has something to flatten wrongly.

Two user states are absent because the management API cannot set them. verifyStatus is NOT_INITIATED on every user it creates, and an account lock is a separate operation and not a field on the user.

Groups that disagree with the data

Eleven groups, and the interesting ones are the disagreements.

The Contractors group holds the Contractors population, and the contractor attribute does not match it: twelve members are flagged false, and one partner flagged true sits outside the group entirely. Any report that treats group membership and an attribute as two views of one fact gets two different answers.

A population-scoped group refuses a user from outside its population, a constraint most group code has never met. The static chain runs three deep, so membership has to resolve transitively, and memberOfGroups on a group is itself transitive: Team Platform, nested only in Engineering, reports both Engineering and All Staff as parents.

Then two dynamic groups, and the part of the design I like most. A dynamic group reports zero members immediately after a seed, because PingOne evaluates filters asynchronously. That is the state the row exists to capture. Beside it sits a second dynamic group whose filter is valid and matches nobody at all, which looks exactly the same from the outside. Telling a group that has not been evaluated yet from a group that will never match anybody is a real problem, and the seed puts both in front of you.

Two APIs and six clients

Above the directory sit the things that consume it. Two custom resources stand in for internal APIs, each with an audience and a token lifetime of its own: an orders API with read, write and admin scopes on a one-hour token, and a reports API with a single read scope on fifteen minutes. A report that assumes one lifetime across an environment has two to reconcile.

Six applications cover the shapes an inventory has to handle. An OIDC web client with a secret, granted a scope on the orders API and open to all staff. A second web client restricted to the one group with a single member, granted the reports scope, which is the pairing an access review should be able to trace end to end. A single-page client with no secret at all. A native client with a custom-scheme redirect and a refresh token. A SAML application that is issued no access tokens and therefore holds no scopes, so anything that expects every application to have some finds one that does not.

And a disabled OIDC client with no group and no scopes, because a disabled application still appears in every listing, and an inventory that counts applications without reading their state overstates what the environment can do by one.

Redirect and ACS URLs are written under the connection’s email domain, so nothing in the seed points at a host somebody owns.

No default, and no public client without PKCE

Three things the provider will never do, with no parameter that would let it.

No seeded population is ever made the environment’s default, since the default decides where every user created without a population lands. No platform application or built-in resource is created, edited or deleted. And no public client is created without PKCE:

1
2

# A public client runs safely only with PKCE, so it is never seeded without it.
if ($row.TokenAuth -eq 'NONE') { $body['pkceEnforcement'] = 'S256_REQUIRED' }

Tests assert each of the three, so adding a -Default or a -DisablePkce switch as a convenience is caught as the regression it would be. Same pattern as the Entra provider’s Conditional Access rule and the Authentik provider’s flows: the safety is the absence of a parameter, which is the only version of it a hurried afternoon cannot talk its way past.

Teardown in the order PingOne allows

Applications, resources, users, groups, populations, and custom attributes last. Each position is forced by what the platform will delete: an attribute cannot go while any user still holds a value in it, and a population cannot go while it holds a user.

That ordering also explains a parameter that would otherwise look inconsistent. -Keep Users refuses to remove the populations and the attributes as well, because PingOne deletes only an empty population and an unreferenced attribute. Keeping the users keeps the three things that depend on them.

The confirmation is asked once, in the body of the command, where a refusal stops the work. A session that cannot answer the prompt counts as a refusal, so an unattended teardown has to pass -Force. -WhatIf always wins over it: -Force -WhatIf removes nothing and prints a line for every object it would have removed. Running teardown again on an already-clean environment removes nothing and reports no error, which is the same property the schema check above exists to protect.

Comparing on the parts

Compare-TestEnvironment matches the people in two connected providers by their shared login key, and PingOne is where that ran into something none of the others had.

PingOne keeps a given name and a family name, and no display name at all. Composing one would be easy and wrong:

1
2
3
4

# PingOne keeps a given name and a family name and no display name, so the display name is
# left empty and the comparison falls back to the parts rather than composing a name the
# environment never stored: a composed one would put the family name last for a person whose
# name puts it first.

The nine people in other writing systems are in this directory too, and at least one of them writes the family name first. A comparison that composed given + " " + family would report a mismatch against the directory that stored the real display name, and the mismatch would be an artefact of the comparison and nothing wrong in either directory.

Leaving the display name empty and comparing the parts gives the right answer for everybody. Run against the lab Entra tenant and this sandbox from one session, 329 people matched on the login key, 328 names compared as given name and surname with none differing, and one account only in PingOne.

Checking it afterwards

Test-TestEnvironment reads the populations, users, groups, applications, resources and attributes the module owns, the same way teardown finds them, and compares them with the seed files: every seeded name present, nothing owned that the data does not describe, every given and family name matching by codepoint, and every group a user row lists holding that user.

Names are compared ordinally and not with -eq, because a decomposed and a precomposed name are equal to -eq and different on the wire. A mangled name is precisely the fault this provider shipped once, and an equality check would have passed against the wrong string. Usernames are compared case-insensitively, since PingOne folds them.

Memberships are read one user at a time and judged on what is missing only. The dynamic group’s filter and the nested chain both add members the data never lists, and reporting those as unexpected would mean reporting the platform working as a fault. -SkipMembership drops those reads, at one call per seeded user that has any.

Repair-TestEnvironment re-runs the seed steps that own whatever failed, which here mostly means re-running one object type instead of four minutes of environment.

Running it

1
2
3
4
5
6
7
8
9

$secret = Read-Host 'Worker secret' -AsSecureString
Connect-TestEnvironment -Provider PingOne -EnvironmentId <sandbox> `
    -ClientId <worker> -ClientSecret $secret -AuthEnvironmentId <administrators> -SaveSecret

New-TestEnvironment -WhatIf
New-TestEnvironment -ShowProgress
Get-TestEnvironmentReport
Test-TestEnvironment
Remove-TestEnvironment -Force

The three hundred bulk users are generated by Tools\New-PingOneTestSeedData.ps1, an authoring tool the module never calls, from the same shared people the other five providers read, with populations, titles, departments and group memberships assigned here. The committed CSVs are the artifact; the tool is deterministic, so regenerating produces byte-identical files and a test fails if the committed copies have drifted. The nineteen designed rows live in the tool verbatim and are never generated.

The worker needs Identity Data Admin, Environment Admin and Client Application Developer on the environment being seeded. Nothing else is installed: Windows PowerShell 5.1 or PowerShell 7, and the module.

Verified against a North America trial sandbox from both editions. The other four regions have not been exercised, and I would rather say so than imply otherwise.

The provider’s page, with the full inventory and every behaviour above in longer form, is at Providers/PingOne/README.md.

That is all six providers: Active Directory, Entra, Okta, Authentik, FreeIPA and this one. Six directories, one set of people, and the same nineteen names in every one of them, so a script that reconciles two of them has two populations that correspond.

Writing the last provider from scratch was the most useful thing I did for the other five. It found the encoding fault at the top of this post, it produced the shared request helper, and it made the differences between the six impossible to ignore, which is how most of the shared surface ended up existing at all.
